Part No: CRS-LOEHS

Category: Listen Only Earpieces
  • Description
  • Specifications

Description

Listen Only Earhook Earpiece with Short Cable 2.5mm / 3.5mm Connector

The design of the listen only short cable earhook earpiece is based on the popular mobile phone style accessory but modified for the radio user. The short cable is only suitable for use in conjunction with a remote speaker microphone. Please refer to CRS-LOEHL if connection is required direct into the radio.

Suitable for all industry types in conjunction with a remote speaker microphone but a particular favourite with security, police, hotel personnel, event co-ordinators…

FEATURES

  • The soft and skin-friendly earhook material provides extreme comfort for long-term wear. The user is provided an element of protection in the event of a scuffle with the flexible soft earhook (no hard plastic breaking or pushing into the side of the head).
  • Pivot design allows for wear in the left or right ear.
  • Super flexible PU cable reinforced with Kevlar for maximum durability.
  • 1 year warranty.

AVAILABLE CONNECTIONS

2.5 mm (J2) connection and 3.5 mm (J6) connection

  1. Electrical Specifications for Speaker
Speaker TypeMylar Speaker
Speaker DimensionsФ15.0 mm
Speaker Impedance32 Ohms±20%
Rated input Power0.1 W
Max. Input Power0.2 W for 1 Minute
Sound Pressure Level111 dB±4dB/1mW at 1KHz
Distortion5% Max. Rated Input at 1KHz
  1. Electrical Specifications for Cable
Open/short circuit standardAt least 20KΩ
Acceptable capacitanceLess than 0.05µF
Open/short circuit test time2.0 seconds
Conductance resistanceLess than 3.00Ω
Input voltage for insulation resistance test300V
Insulation resistance standardAt least 20MΩ
Insulation resistance test time0.01 second
  1. Product Reliability Assurance Test
Storage / Work Environment-40℃~70℃; 24H.
Drop152.4cm; 10 times.
Bending (Cable)±90°; 30cycles/min; 200g load; 10000 cycles.
Pulling (Cable)Cable pulling force: 15Kgf;

Plug, Jack pulling force :5Kgf;

PTT LifeThe test is not applicable
Electronic static dischargeConnect discharge: 8KV; disconnect discharge: 15KV
