Part No: CRS-1WLAT

Category: 1 Wire Earpieces
  • Description
  • Specifications

Description

1 Wire Long Acoustic Airtube Earpiece with Inline PTT/Microphone

The single wire long acoustic airtube earpiece has been designed for covert surveillance where discreet communication is essential. The speaker transducer gives exceptional audio output. The heavy duty PTT design coupled with the sensitive Electret condenser microphone makes this a perfect product for discreet communication in complex environments. The threaded airtube can be removed easily to enable JUST THE ACOUSTIC AIRTUBE to be made personal issue for staff – GREAT SAVING.

Suitable for all industry types but a particular favourite with security, police, casinos, night clubs, hotel personnel, restaurants, private detectives, event co-ordinators…

FEATURES

  • REPLACEABLE LONG AIRTUBE SECTION. The long airtube screw in section of this earpiece (CRS-LATCD) can be purchased separately making it a hygienic, cost saving solution for staff sharing radios and accessories. The bulk of the earpiece stays on the 2way radio and you simply unscrew the long airtube section and make that personal issue to staff. For more information refer to Spares & Options in the Earpieces & Surveillance Kit Section.
  • Surgical grade acoustic tube; discrete and comfortable.
  • Replaceable clothing clip.
  • Adjustable angle on airtube outlet.
  • Super flexible PU cable reinforced with Kevlar for maximum durability.
  • Optional pink ear mould allows ambient sounds to be heard and provides exceptional comfort.
  • Optional noise attenuating earplug ensure more noise is blocked out than standard mushroom eartip – Noise Reduction Rating : NRR 25dB.
  • Electret Condenser Microphone provides superior audio quality.
  • Positive action PTT for reliable transmissions.
  • 1 year warranty.

AVAILABLE CONNECTIONS

CASSIDIAN – NK1
GARMIN RINO 650 – J4
GME –
GME, GU
HARRIS – MC4
HYT – H1S, K1, M1, M5
HYTERA – H4, H5, H6, H8
ICOM – S3W, S4, S6, S8
KENWOOD – K1, K2, K4
KIRISUN –
K1, KR4, M1, M5
MOTOROLA – HR, M1, M3, M4, M5, M6, M7, M10, M12, M14
RELM – M5
SEPURA – STP
SIMOCO
 – M5
TAIT – T1
ToooAir – K1
VERTEX – Y3, Y4, Y6
UNIDEN – J4, GU

  1. Electrical Specifications for Speaker
Speaker TypeMylar Speaker
Speaker DimensionsФ16.0 mm
Speaker Impedance90 Ohms±20%
Rated input Power5mW
Max. Input Power10mW for 1 Minute
Sound Pressure Level99 dB±4dB/1mW at 1KHz
Distortion5% Max. Rated Input at 1KHz
  1. Electrical Specifications for Microphone
Microphone TypeECM Microphone
Microphone DimensionsΦ6.0×2.7mm
Sensitivity-42 dB±3dB/U=2.0 V; R=2.2KΩ at 1KHz
Working Voltage1.0~10V
Current≤0.5mA(U=2.0V,Rf=2.2KΩ)at 1.0KHz
  1. Product Reliability Assurance Test
Storage / Work Environment-40℃~70℃; 24H.
Drop152.4cm; 10 times.
Bending (Cable)±90°; 30cycles/min; 200g load; 10000 cycles.
Pulling (Cable)Cable pulling force: 10Kgf

Plug pulling force: 10Kgf

Adaptor, PTT pulling force: 10Kgf

2-PIN plug pulling force: 5Kgf

Speaker, PTT, microphone pulling force: 5Kgf

PTT Life100000 cycles.
Electronic static dischargeConnect discharge: 8KV; disconnect discharge: 15KV
